Mesa (DM44)

The perfect economical choice for controlled environments facilities is our Mesa (DM44) insulated metal panel. This panel is available in thicknesses up to 8”, offering superior thermal performance for cold storage buildings. Panels are embossed and lightly planked providing a uniform interior wall aesthetic. In addition, panels are available in lengths up to 50 feet long which can minimize panel end joint conditions and improve installation time.
** R-Value tested in accordance with ASTM C518 at 35° F mean temperature

Product Selection

Panel Width(s) Lengths Thicknesses Insulating Properties   “R” Value  ** Installation Orientation Specialty  Info
Mesa (DM44) 44″ 8′ – 50′ Max 2″ 16 Vertical Industrial & Controlled Environment Partition Wall & Ceiling Applications
2.5″ 20
3″ 24
4″ 32
5″ 41
6″ 49
8″ 65
** R-Value tested in accordance with ASTM C518 at 35° F mean temperature adjusted for a windspeed of 15 mph.
*Consult AWIP for required panel lengths longer than the published standard. (Exception – All fire rated panels)
Panel Metal Metal Finish
Exterior Interior Exterior Interior
Profile Std. Gauge Available Gauge Profile Std. Gauge Available Gauge
Mesa (DM44) Embossed & Lightly Planked Mesa Ribs 26 Gauge G90/AZ50 24 and 22 G90/AZ50, 26 304 2B Stainless Steel*** Embossed & Lightly Planked Mesa Ribs 26 Gauge G90/AZ50 24 and 22 G90/AZ50, 26 304 2B Stainless Steel*** PVDF Std. SMP Available Polyester  Std. PVDF & SMP Available

***For interior applications
**** DM44 is for interior application only

Technical Data

Gallery

Features / Benefits

  • Wider modules reduce number of panels and is ideal for controlled environment interior partition walls

  • Composite panel simplifies design, reduces complexity, improves efficiency and reduces installation costs
  • Single component wall design includes clean aesthetic, thermal barrier, and washable surfaces

Technical Data

Panel Width(s) Lengths Thicknesses Insulating Properties   “R” Value  ** Installation Orientation Specialty  Info
Mesa (DM44) 44″ 8′ – 50′ Max 2″ 16 Vertical Industrial & Controlled Environment Partition Wall & Ceiling Applications
2.5″ 20
3″ 24
4″ 32
5″ 41
6″ 49
8″ 65
** R-Value tested in accordance with ASTM C518 at 35° F mean temperature adjusted for a windspeed of 15 mph.
*Consult AWIP for required panel lengths longer than the published standard. (Exception – All fire rated panels)
Panel Metal Metal Finish
Exterior Interior Exterior Interior
Profile Std. Gauge Available Gauge Profile Std. Gauge Available Gauge
Mesa (DM44) Embossed & Lightly Planked Mesa Ribs 26 Gauge G90/AZ50 24 and 22 G90/AZ50, 26 304 2B Stainless Steel*** Embossed & Lightly Planked Mesa Ribs 26 Gauge G90/AZ50 24 and 22 G90/AZ50, 26 304 2B Stainless Steel*** PVDF Std. SMP Available Polyester  Std. PVDF & SMP Available

***For interior applications
**** DM44 is for interior application only
